Observability & Security Hardening
What This Phase Covers
By the end of Phase 3 , the pipeline was green, images were in ECR, and containers were running on EC2. But “running” is not the same as “observable.” I had no idea what wa3s happening inside those containers unless I SSM’d in and ran docker logs manually.
Phase 5 fixes that — and adds the security pieces that turn the project from a demo into something you’d actually trust in production:
CloudWatch agent on every EC2 — container logs shipped automatically, memory and disk metrics collected
Structured JSON logging in the Express API via winston
AWS Secrets Manager — secrets never appear in SSM command history
EBS snapshot lifecycle — automated daily MongoDB backups
npm audit gate — blocks CRITICAL vulnerabilities in CI
Dockerfile health check fix — the frontend container was always “unhealthy”
The Bug I Found: The Container That Lied
Before adding anything new, I discovered the frontend Dockerfile had a broken health check:
1
2
3
4
5
# WRONG — Next.js has no /api/health route
HEALTHCHECK CMD wget -qO- http://localhost:3000/api/health || exit 1
Every time the container ran, Docker was marking it (unhealthy) within 30 seconds. The app was actually running fine — Ready in 369ms appeared in the logs — but Docker’s health status said otherwise.
The fix is one word:
1
2
3
4
5
# Correct — Next.js always returns 200 at /
HEALTHCHECK CMD wget -qO- http://localhost:3000/ || exit 1
The ALB health check (separate from Docker’s) was already checking / and reporting healthy. So the ALB was routing traffic correctly, but docker ps would have shown (unhealthy) to anyone monitoring it. Fixed.
CloudWatch: Seeing Inside the Instances
The Problem With EC2 Defaults
CloudWatch gives you CPU utilization for EC2 by default. That’s it. Memory and disk are not exposed — the hypervisor can’t see inside the OS. And container logs don’t flow anywhere automatically.
The solution is the CloudWatch agent: a small daemon that runs on the EC2 instance, reads from /var/lib/docker/containers/**/*-json.log, and ships those logs to CloudWatch Log Groups. It also collects memory and disk metrics.
Installing the Agent via User Data
Every EC2 instance in this project uses user_data to bootstrap on first boot. I extended that script to install and configure the agent:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
dnf install -y docker amazon-cloudwatch-agent
cat > /opt/aws/amazon-cloudwatch-agent/etc/amazon-cloudwatch-agent.json << 'CWEOF'
{
"logs": {
"logs_collected": {
"files": {
"collect_list": [{
"file_path": "/var/lib/docker/containers/**/*-json.log",
"log_group_name": "/mindcraft/api",
"log_stream_name": "{instance_id}",
"timezone": "UTC"
}]
}
}
},
"metrics": {
"append_dimensions": { "InstanceId": "${aws:InstanceId}" },
"metrics_collected": {
"cpu": { "measurement": ["cpu_usage_idle", "cpu_usage_user"], "metrics_collection_interval": 60, "totalcpu": true },
"disk": { "measurement": ["used_percent"], "metrics_collection_interval": 60, "resources": ["/"] },
"mem": { "measurement": ["mem_used_percent"], "metrics_collection_interval": 60 }
}
}
}
CWEOF
/opt/aws/amazon-cloudwatch-agent/bin/amazon-cloudwatch-agent-ctl \
-a fetch-config -m ec2 -s \
-c file:/opt/aws/amazon-cloudwatch-agent/etc/amazon-cloudwatch-agent.json
One Terraform note: the agent config JSON contains ${aws:InstanceId} — a CW agent template variable. In a Terraform heredoc, ${...} is Terraform interpolation syntax. To prevent Terraform from trying to resolve it, escape the dollar sign: $${aws:InstanceId}. Terraform outputs ${aws:InstanceId} literally in the generated shell script, and the CW agent resolves it at runtime.
Three Separate user_data Scripts
Each EC2 tier ships logs to its own log group (/mindcraft/web, /mindcraft/api, /mindcraft/db). This means three separate user_data locals in terraform/modules/ec2/main.tf — identical Docker setup, different log_group_name.
CloudWatch Terraform Module
Created terraform/modules/cloudwatch/ with:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
# Log groups — 7-day retention to keep costs low
resource "aws_cloudwatch_log_group" "web" {
name = "/mindcraft/web"
retention_in_days = 7
}
# SNS topic for alerts
resource "aws_sns_topic" "alerts" {
name = "mindcraft-alerts"
}
resource "aws_sns_topic_subscription" "email" {
topic_arn = aws_sns_topic.alerts.arn
protocol = "email"
endpoint = var.alert_email
}
# CPU alarm — web tier
resource "aws_cloudwatch_metric_alarm" "web_cpu" {
alarm_name = "mindcraft-web-cpu-high"
comparison_operator = "GreaterThanThreshold"
evaluation_periods = 2
metric_name = "CPUUtilization"
namespace = "AWS/EC2"
period = 300
statistic = "Average"
threshold = 80
alarm_actions = [aws_sns_topic.alerts.arn]
ok_actions = [aws_sns_topic.alerts.arn]
dimensions = { InstanceId = var.web_instance_id }
}
Two CPU alarms (web + API). Threshold 80%, evaluation across 2 periods of 5 minutes — so you get alerted only after 10 sustained minutes of high CPU, not a brief spike.
IAM: The Agent Already Had Permission
The EC2 IAM role already had CloudWatchAgentServerPolicy attached (Phase 2 setup). No new IAM changes needed for CloudWatch — it was pre-positioned.
Structured Logging: Winston in Express
Why Morgan Isn’t Enough
Morgan is an HTTP request logger. It logs GET /api/users 200 12ms and that’s it. It has no concept of severity levels, no JSON format, and no way to add structured fields to application logs.
In production, you want JSON so CloudWatch Logs Insights can query across fields:
1
2
3
{ "level": "error", "method": "POST", "path": "/api/auth/login", "status": 401, "message": "Invalid password" }
The Implementation
Added winston to server/package.json:
1
2
3
"winston": "^3.17.0"
Created server/logger.js:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
import winston from 'winston';
const isProd = process.env.NODE_ENV === 'production';
export const logger = winston.createLogger({
level: isProd ? 'http' : 'debug',
format: isProd
? winston.format.json()
: winston.format.combine(
winston.format.colorize(),
winston.format.simple()
),
transports: [new winston.transports.Console()],
});
// Pipes morgan HTTP logs through winston in production
export const morganStream = {
write: (message) => logger.http(message.trim()),
};
In production: JSON output, http level threshold (so HTTP access logs appear). In dev: colorized human-readable output, debug level. The same logger handles both environments.
In server/index.js:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
// Morgan output piped through winston in production
app.use(morgan(isProd ? 'combined' : 'dev', { stream: isProd ? morganStream : undefined }));
// Error handler uses logger instead of console.error
logger.error(`${req.method} ${req.path}`, { status: err.status, message: err.message });
// Startup
logger.info(`MindCraft API running on port ${PORT}`, { env: process.env.NODE_ENV });
One design decision: level: 'http' in production. Winston’s default level ordering means that if you set level: 'info', HTTP-level messages are silenced (http = priority 3, below info = priority 2). Setting level: 'http' ensures access logs flow while keeping verbose/debug silent.
AWS Secrets Manager: Secrets Off the Command Line
The Problem With Environment Variables in SSM Commands
The previous deploy.yml ran containers like this:
1
2
3
docker run -d --name mindcraft-api --env MONGODB_URI="mongodb://..." ...
That connection string lives in the SSM command history in plaintext. Anyone with ssm:ListCommands on the account can read it.
The Better Pattern
Instead of passing secrets as GitHub Actions secrets into the SSM command directly, the EC2 instance fetches them from Secrets Manager at deploy time:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
MONGODB_URI=$(aws secretsmanager get-secret-value \
--secret-id mindcraft/mongodb-uri \
--query SecretString --output text --region $region)
JWT_SECRET=$(aws secretsmanager get-secret-value \
--secret-id mindcraft/jwt-secret \
--query SecretString --output text --region $region)
GEMINI_API_KEY=$(aws secretsmanager get-secret-value \
--secret-id mindcraft/gemini-api-key \
--query SecretString --output text --region $region)
docker run -d --name mindcraft-api -p 3001:3001 --restart unless-stopped \
--env NODE_ENV=production \
--env MONGODB_URI="$MONGODB_URI" \
--env JWT_SECRET="$JWT_SECRET" \
--env GEMINI_API_KEY="$GEMINI_API_KEY" \
$ecr/mindcraft-api:latest
The secrets are fetched on the EC2 instance using the instance’s IAM role — no credentials required, and the secret values never appear in the SSM command document sent from GitHub Actions.
Secrets Live Outside Terraform
An early version of this project managed the secret resources in Terraform. The problem: terraform destroy deleted the secrets, meaning secret values had to be re-entered after every apply/destroy cycle — even though the actual values (JWT key, Gemini API key) never change.
The fix: secrets are created once via CLI and never touched by Terraform again.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
aws secretsmanager create-secret \
--name mindcraft/jwt-secret \
--secret-string "your-jwt-secret" \
--region ap-southeast-1
aws secretsmanager create-secret \
--name mindcraft/mongodb-uri \
--secret-string "mongodb://10.0.5.10:27017/mindcraft" \
--region ap-southeast-1
aws secretsmanager create-secret \
--name mindcraft/gemini-api-key \
--secret-string "your-gemini-key" \
--region ap-southeast-1
The DB instance has a fixed private IP (10.0.5.10, pinned in the EC2 Terraform resource) so the MongoDB URI is always the same — no update needed after re-apply.
Terraform manages the IAM role that grants access. The secrets themselves persist across any number of destroy/apply cycles. This is the correct boundary: Terraform owns infrastructure, not application secrets.
IAM Scope
The EC2 IAM role can only read secrets in the mindcraft/* namespace:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
resource "aws_iam_role_policy" "secrets_read" {
policy = jsonencode({
Statement = [{
Effect = "Allow"
Action = ["secretsmanager:GetSecretValue"]
Resource = "arn:aws:secretsmanager:*:*:secret:mindcraft/*"
}]
})
}
Frontend: Build-Time Variable
NEXT_PUBLIC_API_URL is different — it’s baked into the JavaScript bundle at build time (Next.js’s NEXT_PUBLIC_ prefix convention). It can’t be injected at docker run time.
Fixed in Dockerfile.frontend:
1
2
3
4
5
6
7
ARG NEXT_PUBLIC_API_URL
ENV NEXT_PUBLIC_API_URL=$NEXT_PUBLIC_API_URL
RUN npm run build
And in deploy.yml:
1
2
3
4
5
6
7
8
9
10
11
12
13
- name: Build frontend image
run: |
docker build -f Dockerfile.frontend \
--build-arg NEXT_PUBLIC_API_URL=$ \
-t $ECR_REGISTRY/mindcraft-frontend:$ \
.
EBS Snapshot Lifecycle: Automated MongoDB Backups
MongoDB data lives on a separate 20GB gp3 EBS volume (/dev/sdf). Without snapshots, a terminated instance means lost data.
AWS Data Lifecycle Manager (DLM) automates this:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
resource "aws_dlm_lifecycle_policy" "mongodb_snapshot" {
description = "Daily MongoDB EBS snapshot, 7-day retention"
execution_role_arn = aws_iam_role.dlm.arn
state = "ENABLED"
policy_details {
resource_types = ["VOLUME"]
schedule {
name = "Daily"
create_rule {
interval = 24
interval_unit = "HOURS"
times = ["02:00"]
}
retain_rule { count = 7 }
copy_tags = true
}
target_tags = {
Name = "mindcraft-mongodb-data"
}
}
}
DLM matches volumes by the Name tag, takes a snapshot at 02:00 UTC daily, and deletes snapshots older than 7. Zero manual steps.
npm Audit Gate in CI
Added a npm-audit job to security.yml that runs before Trivy:
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
npm-audit:
name: npm audit
runs-on: ubuntu-latest
steps:
- uses: actions/checkout@v4
- uses: actions/setup-node@v4
with:
node-version: "20"
cache: "npm"
- name: Audit frontend dependencies
run: |
npm ci
npm audit --audit-level=critical
- name: Audit API dependencies
working-directory: server
run: |
npm install
npm audit --audit-level=critical
--audit-level=critical — only fail on CRITICAL severity. This mirrors the Trivy policy (ignore-unfixed, CRITICAL only). HIGH vulnerabilities are surfaced in the audit output but don’t block the build — transitive HIGH vulns in build tools are common and often unfixable.
What’s Left
HTTPS — requires a registered domain and ACM certificate. Deferred: the ALB is ready (HTTP listener on 80), adding HTTPS is two Terraform resources once you have a domain.
MongoDB TLS — certificate management between containers adds complexity. Deferred.
CloudWatch dashboard — the log groups and metrics are flowing; a Terraform
aws_cloudwatch_dashboardresource with JSON widget config is the remaining step.
The New Terraform Module Count
Phase 2 provisioned 35 resources. After Phase 5:
terraform/modules/cloudwatch/— 7 resources (3 log groups + SNS topic + subscription + 2 CPU alarms)terraform/modules/secrets/— 3 resources (3 Secrets Manager secrets)terraform/modules/ec2/main.tfadditions — DLM role + policy attachment + lifecycle policy (3 resources)
Total: ~48 resources on next apply.
What Actually Happened
The first time I ran terraform plan after adding the cloudwatch module, I hit a subtle Terraform escape issue. The CloudWatch agent config JSON contains ${aws:InstanceId} — a CW agent template variable. Inside a Terraform heredoc, ${ triggers Terraform interpolation and the plan fails with:
1
2
3
Error: Invalid template control keyword
Fix: escape to $${aws:InstanceId} in the Terraform template. Terraform writes ${aws:InstanceId} literally into the generated shell script; the CW agent resolves it at runtime. One character, completely non-obvious if you haven’t seen it before.
You can find me online at:
