Containerizing a 3-Tier MERN Stack With Docker Compose — Phase 2 Walkthrough

Phase 1 gave us a working MERN stack running locally — Next.js on port 3000, Express API on port 3001, MongoDB on port 27017, all running as bare Node processes on the host machine.

Phase 2 goal: wrap all three into Docker containers so the entire stack starts with one command and runs identically on any machine, no local installs required.

docker compose up

That’s the finish line. Here’s what it took to get there.

---

What We’re Containerizing

Three services, three containers:

Container	Image	Purpose	Port
mindcraft-frontend	Custom build	Next.js — serves the React app	3000 (public)
mindcraft-api	Custom build	Express — REST API + JWT auth	3001 (public for local dev)
mindcraft-db	mongo:7	MongoDB — database tier	27017 (internal only)

The key constraint: MongoDB should never be reachable from outside the stack. In production on AWS, a Security Group enforces this at the network level. In Docker Compose, we enforce it with Docker networks.

---

The Dockerfiles

Express API — Dockerfile.api

# Stage 1 — install production dependencies only
FROM node:20-alpine AS deps
WORKDIR /app
COPY server/package*.json ./
RUN npm ci --omit=dev

# Stage 2 — runtime image
FROM node:20-alpine AS runner
WORKDIR /app

RUN addgroup --system --gid 1001 nodejs && \
    adduser --system --uid 1001 express
USER express

COPY --from=deps --chown=express:nodejs /app/node_modules ./node_modules
COPY --chown=express:nodejs server/ .

EXPOSE 3001
ENV NODE_ENV=production

HEALTHCHECK --interval=30s --timeout=5s --start-period=10s --retries=3 \
  CMD wget -qO- http://localhost:3001/health || exit 1

CMD ["node", "index.js"]

Two stages. Stage 1 installs only production dependencies (--omit=dev). Stage 2 copies those into a fresh image. The build tools (npm, package.json devDeps) never make it into the final image — smaller attack surface, smaller image size.

Non-root user. The process runs as express (uid 1001), not root. If an attacker gets code execution inside the container, they can’t write to the filesystem or escalate to root.

Health check. Docker Compose uses this to know when the API is actually ready — not just started, but responding. The depends_on chain waits for healthy status before starting the next container.

Next.js Frontend — Dockerfile.frontend

# Stage 1 — build
FROM node:20-alpine AS builder
WORKDIR /app
COPY package*.json ./
RUN npm ci
COPY . .
ENV NEXT_TELEMETRY_DISABLED=1
RUN npm run build

# Stage 2 — slim runtime
FROM node:20-alpine AS runner
WORKDIR /app

RUN addgroup --system --gid 1001 nodejs && \
    adduser --system --uid 1001 nextjs
USER nextjs

ENV NODE_ENV=production
ENV NEXT_TELEMETRY_DISABLED=1
ENV PORT=3000

COPY --from=builder --chown=nextjs:nodejs /app/.next/standalone ./
COPY --from=builder --chown=nextjs:nodejs /app/.next/static ./.next/static
COPY --from=builder --chown=nextjs:nodejs /app/public ./public

EXPOSE 3000
CMD ["node", "server.js"]

The standalone output. Next.js has a build mode that produces a self-contained bundle with only what’s needed to run — no node_modules, no source files. It’s enabled in next.config.mjs:

export default { output: 'standalone' };

This cut the final image from ~1.2GB (full node_modules) to ~200MB.

Issue we hit: The config file was named next.config.cjs — Next.js only recognizes next.config.js and next.config.mjs. The build succeeded and compiled all 36 pages, but .next/standalone was never created because the config was silently ignored. The fix was renaming to next.config.mjs and converting module.exports to export default.

---

The Docker Compose File

services:

  mongodb:
    image: mongo:7
    container_name: mindcraft-db
    restart: unless-stopped
    environment:
      MONGO_INITDB_ROOT_USERNAME: ${MONGO_ROOT_USER}
      MONGO_INITDB_ROOT_PASSWORD: ${MONGO_ROOT_PASSWORD}
      MONGO_INITDB_DATABASE: mindcraft
    volumes:
      - mongo-data:/data/db
    networks:
      - backend-net
    healthcheck:
      test: ["CMD", "mongosh", "--eval", "db.adminCommand('ping')"]
      interval: 10s
      timeout: 5s
      retries: 5
      start_period: 20s

  api:
    build:
      context: .
      dockerfile: Dockerfile.api
    container_name: mindcraft-api
    depends_on:
      mongodb:
        condition: service_healthy
    environment:
      NODE_ENV: production
      MONGODB_URI: mongodb://${MONGO_ROOT_USER}:${MONGO_ROOT_PASSWORD}@mongodb:27017/mindcraft?authSource=admin
      JWT_SECRET: ${JWT_SECRET}
      FRONTEND_URL: ${FRONTEND_URL:-http://localhost:3000}
    ports:
      - "3001:3001"
    networks:
      - frontend-net
      - backend-net
    healthcheck:
      test: ["CMD", "wget", "-qO-", "http://localhost:3001/health"]

  frontend:
    build:
      context: .
      dockerfile: Dockerfile.frontend
    container_name: mindcraft-frontend
    depends_on:
      api:
        condition: service_healthy
    environment:
      NEXT_PUBLIC_API_URL: ${NEXT_PUBLIC_API_URL:-http://localhost:3001}
    ports:
      - "3000:3000"
    networks:
      - frontend-net

volumes:
  mongo-data:
    driver: local

networks:
  frontend-net:
    driver: bridge
  backend-net:
    driver: bridge
    internal: true   # ← MongoDB is unreachable from outside this network

Three things worth explaining:

1. Network Isolation

Two Docker networks:

• frontend-net — frontend and API both connect here. Frontend talks to API.
• backend-net — API and MongoDB both connect here. API talks to MongoDB.

MongoDB is only on backend-net. The frontend container is only on frontend-net. That means the frontend container cannot reach MongoDB directly — ever. It has to go through the API. This mirrors the AWS Security Group setup:

Browser → port 3000 → Frontend container
                           ↓
                      port 3001 (frontend-net)
                           ↓
                      API container
                           ↓
                      port 27017 (backend-net)
                           ↓
                      MongoDB container (not reachable from anywhere else)

internal: true on backend-net means Docker won’t create a route out of that network to the host or the internet.

2. Startup Order with Health Checks

depends_on with condition: service_healthy means:

1. MongoDB starts → waits until mongosh ping succeeds → marked healthy
2. API starts → waits until /health returns 200 → marked healthy
3. Frontend starts

Without this, the API would try to connect to MongoDB before MongoDB is ready and crash. Without the API health check, the frontend would try to reach an API that isn’t accepting requests yet.

3. Environment Variables

Nothing is hardcoded. Every secret comes from .env at runtime:

# .env (never committed — in .gitignore)
MONGO_ROOT_USER=admin
MONGO_ROOT_PASSWORD=changeme
JWT_SECRET=your-32-char-secret-here
GEMINI_API_KEY=your-key-here

The compose file references them as ${VARIABLE_NAME}. This is the same pattern used in production with AWS Secrets Manager — the application code never sees where the secret comes from, only its value.

---

What Went Wrong (And Why)

Problem 1: next.config.cjs not recognized

Symptom: Frontend built successfully — 36 pages compiled — but the Docker image failed with:

"/app/.next/standalone": not found

Root cause: package.json has "type": "module", so .js files are ESM. The config was named .cjs to use CommonJS syntax, but Next.js only looks for next.config.js or next.config.mjs. It silently skipped the file, output: 'standalone' was never applied, and the standalone directory was never generated.

Fix: Rename to next.config.mjs, replace module.exports = with export default.

Problem 2: MongoDB auth mismatch

Symptom: API container logs showed MongoDB connection error: Authentication failed in a restart loop.

Root cause: The mongo-data Docker volume had been created in an earlier docker compose up run before we set MONGO_ROOT_USER and MONGO_ROOT_PASSWORD in .env. MongoDB only runs its initialization scripts (setting the root user/password) when the data directory is empty. Since the volume already existed, it kept the old state — which had no auth configured at all.

Fix:

docker compose down -v   # -v removes the named volumes
docker compose up -d     # fresh volume → MongoDB initializes with correct credentials

Warning: down -v deletes all data in the volume. In production, you’d restore from a backup instead of destroying the volume.

---

The Build Commands

# Build both images
docker compose build

# Build a single service
docker compose build api
docker compose build frontend

# Start the full stack (detached)
docker compose up -d

# View logs for a specific container
docker logs mindcraft-api
docker logs mindcraft-frontend
docker logs mindcraft-db

# Check container status and health
docker compose ps

# Stop everything (keep volumes)
docker compose down

# Stop everything AND delete volumes (fresh start)
docker compose down -v

# Rebuild and restart a single service after a code change
docker compose up -d --build api

---

Answering the Sync Question

“Shouldn’t the Docker MongoDB be synced with the existing local database?”

No — and that’s intentional. The Docker MongoDB is a completely separate database from the local MongoDB installation on the host machine. They don’t share data, and they shouldn’t.

Here’s why:

• The local MongoDB (localhost:27017, no auth) is your development database — you connect to it directly with Compass, run the server with npm run dev, and it has no password.
• The Docker MongoDB (mongodb container, auth required) is your integration testing database — it runs with authentication, inside the network isolation, exactly as it will in production.

These are two separate environments. Data in one doesn’t affect the other.

If you want to copy your local data into Docker, you can dump and restore:

# Export from local MongoDB
mongodump --uri="mongodb://localhost:27017/mindcraft" --out=./backup

# Import into Docker MongoDB
mongorestore --uri="mongodb://admin:changeme@localhost:27017/mindcraft?authSource=admin" ./backup/mindcraft

But for testing purposes, starting fresh is actually better — it verifies that the registration and login flow works end-to-end without relying on pre-existing data.

---

Result

$ docker compose up -d
✓ Container mindcraft-db       Healthy
✓ Container mindcraft-api      Healthy
✓ Container mindcraft-frontend Started

$ curl http://localhost:3001/health
{"status":"ok","timestamp":"...","env":"production"}

The full MindCraft stack — Next.js frontend, Express API, MongoDB — runs in Docker with a single command. The database is isolated behind an internal network. Credentials come from environment variables. Each container runs as a non-root user.

Phase 3 takes this same stack and provisions the AWS infrastructure to run it in production.

Source: github.com/Mhdomer/mindcraft-aws-migration
