What is Kubernetes?

Kubernetes (K8s) is a container orchestration platform. Where Docker runs a single container, Kubernetes manages thousands of containers across many machines — scheduling, scaling, healing, and networking them automatically.

Core job of Kubernetes:

• Run your containers reliably across a cluster
• Restart them if they crash
• Scale up/down based on load
• Route traffic to healthy instances
• Roll out updates with zero downtime

---

Architecture

The Cluster

A Kubernetes cluster has two types of machines:

┌─────────────────────────────────────────────────┐
│                  CONTROL PLANE                   │
│  kube-apiserver  etcd  scheduler  controller-mgr │
└─────────────────────────────────────────────────┘
          │              │              │
   ┌──────┴──┐    ┌──────┴──┐   ┌──────┴──┐
   │  Node 1  │    │  Node 2  │   │  Node 3  │
   │  kubelet │    │  kubelet │   │  kubelet │
   │  kube-  │    │  kube-  │   │  kube-  │
   │  proxy   │    │  proxy   │   │  proxy   │
   └─────────┘    └─────────┘   └─────────┘

Control Plane components:

Component	Role
kube-apiserver	The front door — all kubectl commands hit this REST API
etcd	Distributed key-value store — the cluster’s source of truth
kube-scheduler	Decides which node a new pod runs on
kube-controller-manager	Runs control loops (ReplicaSet, Node, Endpoint controllers)
cloud-controller-manager	Integrates with cloud provider (AWS, GCP, Azure)

Worker Node components:

Component	Role
kubelet	Agent on each node — ensures containers are running
kube-proxy	Maintains network rules for Service routing
container runtime	Actually runs containers (containerd, CRI-O)

---

Installing kubectl and a Local Cluster

kubectl — the CLI

# Linux
curl -LO "https://dl.k8s.io/release/$(curl -sL https://dl.k8s.io/release/stable.txt)/bin/linux/amd64/kubectl"
chmod +x kubectl && sudo mv kubectl /usr/local/bin/

# Verify
kubectl version --client

Local cluster options

Tool	Best for
minikube	Learning, single-node
kind (K8s in Docker)	CI pipelines, testing
k3s	Lightweight, Raspberry Pi, edge
Docker Desktop	Mac/Windows dev

# minikube
minikube start
minikube start --driver=docker --cpus=4 --memory=4g

# kind
kind create cluster
kind create cluster --name mylab

# k3s (single command install)
curl -sfL https://get.k3s.io | sh -

kubectl context and config

kubectl config get-contexts                  # list all clusters/contexts
kubectl config current-context              # which cluster you're talking to
kubectl config use-context minikube         # switch cluster
kubectl config set-context --current --namespace=dev  # set default namespace
cat ~/.kube/config                          # raw kubeconfig file

---

Core Objects (Resources)

Everything in Kubernetes is a resource — you describe the desired state in YAML and kubectl applies it.

The basic pattern

kubectl apply -f resource.yaml     # create or update
kubectl delete -f resource.yaml    # delete
kubectl get pods                   # list
kubectl describe pod mypod         # detailed info + events
kubectl edit pod mypod             # live edit in $EDITOR

---

Pods

A Pod is the smallest deployable unit — one or more containers that share a network and storage.

# pod.yaml
apiVersion: v1
kind: Pod
metadata:
  name: myapp
  labels:
    app: myapp
spec:
  containers:
    - name: app
      image: nginx:alpine
      ports:
        - containerPort: 80
      resources:
        requests:
          memory: "64Mi"
          cpu: "250m"
        limits:
          memory: "128Mi"
          cpu: "500m"
      env:
        - name: ENV
          value: "production"
      readinessProbe:
        httpGet:
          path: /
          port: 80
        initialDelaySeconds: 5
        periodSeconds: 10
      livenessProbe:
        httpGet:
          path: /healthz
          port: 80
        initialDelaySeconds: 15
        periodSeconds: 20

kubectl apply -f pod.yaml
kubectl get pods
kubectl get pods -o wide           # show node and IP
kubectl logs myapp                 # container stdout
kubectl logs myapp -f              # follow
kubectl logs myapp -c sidecar      # specific container in multi-container pod
kubectl exec -it myapp -- bash     # shell inside pod
kubectl delete pod myapp

You almost never create naked Pods in production — use Deployments instead (they recreate pods if they die).

---

Namespaces

Namespaces are virtual clusters within a cluster — used for isolation between teams/environments.

kubectl get namespaces
kubectl create namespace staging
kubectl delete namespace staging

# Run commands in a specific namespace
kubectl get pods -n staging
kubectl get pods --all-namespaces      # or -A
kubectl apply -f app.yaml -n staging

Default namespaces: default, kube-system, kube-public, kube-node-lease

---

Deployments

A Deployment manages a set of identical Pods (replicas), handles rolling updates, and restarts crashed pods.

# deployment.yaml
apiVersion: apps/v1
kind: Deployment
metadata:
  name: myapp
  namespace: default
spec:
  replicas: 3
  selector:
    matchLabels:
      app: myapp
  strategy:
    type: RollingUpdate
    rollingUpdate:
      maxUnavailable: 1
      maxSurge: 1
  template:
    metadata:
      labels:
        app: myapp
    spec:
      containers:
        - name: app
          image: nginx:1.25
          ports:
            - containerPort: 80
          resources:
            requests:
              cpu: "100m"
              memory: "128Mi"
            limits:
              cpu: "500m"
              memory: "256Mi"

kubectl apply -f deployment.yaml
kubectl get deployments
kubectl get pods                             # see the 3 replica pods
kubectl rollout status deployment/myapp     # watch rollout progress

# Scale
kubectl scale deployment myapp --replicas=5

# Update image (triggers rolling update)
kubectl set image deployment/myapp app=nginx:1.26

# Rollout history and rollback
kubectl rollout history deployment/myapp
kubectl rollout undo deployment/myapp
kubectl rollout undo deployment/myapp --to-revision=2

# Delete
kubectl delete deployment myapp

---

Services

A Service gives a stable DNS name and IP to a set of Pods (selected by label). Pods come and go, but the Service stays.

Service types

Type	Use case
ClusterIP	Internal only — default, reachable within cluster
NodePort	Exposes on a port on every node (30000–32767)
LoadBalancer	Cloud load balancer (AWS ELB, GCP LB)
ExternalName	DNS alias to an external hostname

# service.yaml
apiVersion: v1
kind: Service
metadata:
  name: myapp-svc
spec:
  selector:
    app: myapp          # matches pods with this label
  ports:
    - protocol: TCP
      port: 80          # service port (what clients call)
      targetPort: 80    # container port (where traffic goes)
  type: ClusterIP

kubectl apply -f service.yaml
kubectl get services
kubectl describe service myapp-svc

# Test from inside the cluster
kubectl run test --rm -it --image=busybox -- wget -qO- http://myapp-svc

# NodePort — access via any node IP
kubectl expose deployment myapp --type=NodePort --port=80
minikube service myapp --url        # get the URL in minikube

---

Ingress

An Ingress routes HTTP/HTTPS traffic from outside the cluster to Services based on hostname or path. Requires an Ingress Controller (nginx-ingress, Traefik, etc.).

# Install nginx ingress controller (minikube)
minikube addons enable ingress

# Install via Helm (production)
helm upgrade --install ingress-nginx ingress-nginx \
  --repo https://kubernetes.github.io/ingress-nginx \
  --namespace ingress-nginx --create-namespace

# ingress.yaml
apiVersion: networking.k8s.io/v1
kind: Ingress
metadata:
  name: myapp-ingress
  annotations:
    nginx.ingress.kubernetes.io/rewrite-target: /
spec:
  ingressClassName: nginx
  rules:
    - host: myapp.example.com
      http:
        paths:
          - path: /
            pathType: Prefix
            backend:
              service:
                name: myapp-svc
                port:
                  number: 80
          - path: /api
            pathType: Prefix
            backend:
              service:
                name: api-svc
                port:
                  number: 8000
  tls:
    - hosts:
        - myapp.example.com
      secretName: myapp-tls

kubectl apply -f ingress.yaml
kubectl get ingress
kubectl describe ingress myapp-ingress

---

ConfigMaps and Secrets

ConfigMap — non-sensitive configuration

apiVersion: v1
kind: ConfigMap
metadata:
  name: app-config
data:
  APP_ENV: production
  LOG_LEVEL: info
  config.yaml: |
    server:
      port: 8080
      timeout: 30s

kubectl create configmap app-config --from-literal=APP_ENV=production
kubectl create configmap app-config --from-file=config.yaml
kubectl get configmap app-config -o yaml

Use in a Pod:

# As environment variables
envFrom:
  - configMapRef:
      name: app-config

# As a mounted file
volumes:
  - name: config-vol
    configMap:
      name: app-config
containers:
  - volumeMounts:
      - name: config-vol
        mountPath: /etc/app

Secret — sensitive data (base64 encoded)

kubectl create secret generic db-creds \
  --from-literal=username=admin \
  --from-literal=password=supersecret

kubectl get secret db-creds -o yaml
echo "c3VwZXJzZWNyZXQ=" | base64 -d    # decode a secret value

# Use in a Pod as env vars
env:
  - name: DB_PASSWORD
    valueFrom:
      secretKeyRef:
        name: db-creds
        key: password

# Or mount as files
volumes:
  - name: secrets-vol
    secret:
      secretName: db-creds

Secrets are base64, not encrypted by default — use Sealed Secrets, Vault, or cloud KMS for real encryption at rest.

---

Persistent Storage

PersistentVolume (PV) and PersistentVolumeClaim (PVC)

# PVC — claim storage (you rarely define PVs manually; cloud providers do it)
apiVersion: v1
kind: PersistentVolumeClaim
metadata:
  name: db-storage
spec:
  accessModes:
    - ReadWriteOnce        # one node can read/write
  resources:
    requests:
      storage: 5Gi
  storageClassName: standard

Access modes:

• ReadWriteOnce (RWO) — one node, read/write
• ReadOnlyMany (ROX) — many nodes, read only
• ReadWriteMany (RWX) — many nodes, read/write (requires NFS or cloud FS)

# Use in a Pod
volumes:
  - name: db-vol
    persistentVolumeClaim:
      claimName: db-storage
containers:
  - volumeMounts:
      - name: db-vol
        mountPath: /var/lib/postgresql/data

kubectl get pvc
kubectl get pv
kubectl describe pvc db-storage

---

StatefulSets

StatefulSets are for stateful apps (databases, queues) that need:

• Stable, predictable pod names (db-0, db-1, db-2)
• Stable persistent storage per pod
• Ordered startup and shutdown

apiVersion: apps/v1
kind: StatefulSet
metadata:
  name: postgres
spec:
  serviceName: postgres
  replicas: 3
  selector:
    matchLabels:
      app: postgres
  template:
    metadata:
      labels:
        app: postgres
    spec:
      containers:
        - name: postgres
          image: postgres:16
          env:
            - name: POSTGRES_PASSWORD
              valueFrom:
                secretKeyRef:
                  name: db-creds
                  key: password
          volumeMounts:
            - name: data
              mountPath: /var/lib/postgresql/data
  volumeClaimTemplates:
    - metadata:
        name: data
      spec:
        accessModes: ["ReadWriteOnce"]
        resources:
          requests:
            storage: 10Gi

---

Resource Management

Requests vs Limits

resources:
  requests:
    cpu: "100m"       # minimum guaranteed (1000m = 1 CPU core)
    memory: "128Mi"   # minimum guaranteed
  limits:
    cpu: "500m"       # hard cap — throttled if exceeded
    memory: "256Mi"   # hard cap — OOMKilled if exceeded

• Requests — used by the scheduler to decide which node to place the pod on
• Limits — enforced at runtime; memory limit breach = pod killed

LimitRange and ResourceQuota

# LimitRange — default limits for a namespace
apiVersion: v1
kind: LimitRange
metadata:
  name: default-limits
  namespace: dev
spec:
  limits:
    - type: Container
      default:
        cpu: "500m"
        memory: "256Mi"
      defaultRequest:
        cpu: "100m"
        memory: "128Mi"

# ResourceQuota — total cap for a namespace
apiVersion: v1
kind: ResourceQuota
metadata:
  name: dev-quota
  namespace: dev
spec:
  hard:
    pods: "20"
    requests.cpu: "4"
    requests.memory: 4Gi
    limits.cpu: "8"
    limits.memory: 8Gi

---

Horizontal Pod Autoscaler (HPA)

Automatically scales the number of pod replicas based on CPU/memory.

kubectl autoscale deployment myapp --cpu-percent=70 --min=2 --max=10
kubectl get hpa
kubectl describe hpa myapp

apiVersion: autoscaling/v2
kind: HorizontalPodAutoscaler
metadata:
  name: myapp-hpa
spec:
  scaleTargetRef:
    apiVersion: apps/v1
    kind: Deployment
    name: myapp
  minReplicas: 2
  maxReplicas: 10
  metrics:
    - type: Resource
      resource:
        name: cpu
        target:
          type: Utilization
          averageUtilization: 70

Requires the metrics-server to be running.

---

Jobs and CronJobs

Job — run a task to completion

apiVersion: batch/v1
kind: Job
metadata:
  name: db-migrate
spec:
  template:
    spec:
      containers:
        - name: migrate
          image: myapp:latest
          command: ["python", "manage.py", "migrate"]
      restartPolicy: OnFailure
  backoffLimit: 3

CronJob — scheduled job

apiVersion: batch/v1
kind: CronJob
metadata:
  name: nightly-backup
spec:
  schedule: "0 2 * * *"        # cron syntax
  jobTemplate:
    spec:
      template:
        spec:
          containers:
            - name: backup
              image: myapp:latest
              command: ["/scripts/backup.sh"]
          restartPolicy: OnFailure
  successfulJobsHistoryLimit: 3
  failedJobsHistoryLimit: 1

kubectl get jobs
kubectl get cronjobs
kubectl logs job/db-migrate

---

RBAC — Role-Based Access Control

ServiceAccount

Every pod runs as a ServiceAccount (default: default). Create dedicated ones:

kubectl create serviceaccount myapp-sa

Role and RoleBinding (namespace-scoped)

# Role — what actions are allowed
apiVersion: rbac.authorization.k8s.io/v1
kind: Role
metadata:
  name: pod-reader
  namespace: default
rules:
  - apiGroups: [""]
    resources: ["pods", "pods/log"]
    verbs: ["get", "list", "watch"]

# RoleBinding — who gets the Role
apiVersion: rbac.authorization.k8s.io/v1
kind: RoleBinding
metadata:
  name: read-pods
  namespace: default
subjects:
  - kind: ServiceAccount
    name: myapp-sa
    namespace: default
roleRef:
  kind: Role
  name: pod-reader
  apiGroup: rbac.authorization.k8s.io

Use ClusterRole + ClusterRoleBinding for cluster-wide permissions.

---

Helm — Kubernetes Package Manager

Helm is to Kubernetes what apt is to Ubuntu — it installs pre-packaged applications called charts.

# Install Helm
curl https://raw.githubusercontent.com/helm/helm/main/scripts/get-helm-3 | bash

helm version
helm repo add stable https://charts.helm.sh/stable
helm repo add bitnami https://charts.bitnami.com/bitnami
helm repo update

# Search and install
helm search repo bitnami/postgresql
helm install my-postgres bitnami/postgresql --set auth.postgresPassword=secret

# List installed releases
helm list
helm list -A               # all namespaces

# Upgrade and rollback
helm upgrade my-postgres bitnami/postgresql --set image.tag=16
helm rollback my-postgres 1

# Uninstall
helm uninstall my-postgres

---

kubectl Cheat Sheet

# Get resources
kubectl get pods,svc,deploy                # multiple types at once
kubectl get pods -o wide                   # show node and IP
kubectl get pods -o yaml                   # full YAML output
kubectl get pods -l app=myapp              # filter by label
kubectl get pods --field-selector=status.phase=Running
kubectl get all -n staging                 # everything in a namespace

# Describe (events are at the bottom — check these first when debugging)
kubectl describe pod mypod
kubectl describe node worker-1

# Logs
kubectl logs mypod
kubectl logs -f mypod                      # follow
kubectl logs mypod --previous             # logs from crashed previous container
kubectl logs -l app=myapp --all-containers # all pods matching label

# Exec
kubectl exec -it mypod -- bash
kubectl exec -it mypod -c sidecar -- sh   # specific container

# Port forward (for local testing)
kubectl port-forward pod/mypod 8080:80
kubectl port-forward svc/myapp-svc 8080:80
kubectl port-forward deployment/myapp 8080:80

# Copy files
kubectl cp mypod:/etc/config.yaml ./config.yaml
kubectl cp ./local.txt mypod:/tmp/local.txt

# Apply, delete, diff
kubectl apply -f .                        # apply all YAML in current dir
kubectl apply -f https://example.com/manifest.yaml
kubectl delete -f deployment.yaml
kubectl diff -f deployment.yaml           # what would change

# Dry run
kubectl apply -f deployment.yaml --dry-run=client
kubectl apply -f deployment.yaml --dry-run=server

# Generate YAML skeletons
kubectl create deployment myapp --image=nginx --dry-run=client -o yaml > deploy.yaml
kubectl create service clusterip myapp --tcp=80:80 --dry-run=client -o yaml

# Labels and annotations
kubectl label pod mypod env=production
kubectl annotate pod mypod team=backend
kubectl get pods -l env=production

# Drain and cordon nodes (maintenance)
kubectl cordon node-1                     # stop scheduling new pods
kubectl drain node-1 --ignore-daemonsets # evict pods
kubectl uncordon node-1                  # re-enable scheduling

# Events — great for debugging
kubectl get events --sort-by='.lastTimestamp'
kubectl get events -n staging

---

Debugging Patterns

Pod won’t start:

kubectl describe pod mypod        # look at Events section at the bottom
kubectl logs mypod --previous     # logs before the crash

Common statuses:

• Pending — not scheduled yet (check node resources, taints, affinities)
• CrashLoopBackOff — container keeps crashing (check logs)
• ImagePullBackOff — can’t pull image (check image name, registry credentials)
• OOMKilled — exceeded memory limit (increase limits)
• Evicted — node was under pressure (check node disk/memory)

Service not reachable:

kubectl get endpoints myapp-svc   # should show pod IPs — if empty, labels don't match
kubectl exec -it debug -- wget -qO- http://myapp-svc    # test from inside cluster

Check node health:

kubectl get nodes
kubectl describe node worker-1    # check Conditions and Events
kubectl top nodes                 # CPU/memory usage (needs metrics-server)
kubectl top pods

---

Quick Reference

Task	Command
Apply a manifest	kubectl apply -f file.yaml
Get pods	kubectl get pods -o wide
Shell into pod	kubectl exec -it pod -- bash
View logs	kubectl logs -f pod
Port forward	kubectl port-forward svc/name 8080:80
Scale deployment	kubectl scale deploy/name --replicas=5
Update image	kubectl set image deploy/name app=img:tag
Rollback	kubectl rollout undo deploy/name
Watch rollout	kubectl rollout status deploy/name
Get all resources	kubectl get all -n namespace
Debug events	kubectl get events --sort-by='.lastTimestamp'
Switch context	kubectl config use-context name
Switch namespace	kubectl config set-context --current --namespace=ns
Install Helm chart	helm install name repo/chart
List Helm releases	helm list -A
